EC92

by MD0MDI
6JB6A Valve

Quantity in Stock

11

Location

Box E.1

The EC92 is a single triode designed for use as a mixer, amplifier or oscillator in VHF television receivers.

The heater is controlled in both voltage and current requirements so that it can be used for parallel or series heater chains.



It appears to be a miniature replacement for the EC52 low power VHF oscillator valve.

B7G Base
EC90 Schematic Symbol
EC90 Pinouts

Pin 1 : Anode
Pin 2 : Not Connected
Pin 3 : Heater
Pin 4 : Heater
Pin 5 : Anode
Pin 6 : Grid
Pin 7 : Cathode

Specifications

Vf : 6.3v
If : 150mA
Va : 250v
Vg : -2.0v
mAa : 10mA
Ra : 11kΩ

Substitutes

6AB4

Datasheets

EC92 La Radiotechnique Datasheet

EC92 La Radiotechnique Datasheet

Icon
35.49 KB 28 downloads

EC92 Philips Datasheet 1

EC92 Philips Datasheet 1

Icon
37.37 KB 9 downloads

EC92 Philips Datasheet 2

EC92 Philips Datasheet 2

Icon
38.76 KB 7 downloads

EC92 RFT Datasheet

EC92 RFT Datasheet

Icon
89.48 KB 11 downloads

Thanks to the Valve Museum for the information collected here.
